solie220

SOLA/HEVI-DUTY IE220 ACTIVE TRK FILTER1PH 20A 240V DIN

Name: SOLA/HEVI-DUTY IE220 ACTIVE TRK FILTER1PH 20A 240V DIN
Brand: SOLA/HEVI-DUTY
SKU: solie220
Availability: OutOfStock

Where to buy this product?

Manufacturer:SOLA/HEVI-DUTY

Manufacturer #:IE220

Description

Islatrol IE Series Active Tracking Filter, 240 V/Continuous Current 20 Amps

Brand Name	SolaHD	Sub Brand	Edco
Type	Surge Protective Devices	Voltage Rating	240 V
Short Circuit Rating	Surge current capacity -- 45,000 Amps	Amperage Rating	10 A
Frequency Rating	47-63 Hz	Response Time	Normal Mode <0.5ns; Common Mode <5ns
Phase	1	Mounting	DIN/Flange
Environmental Conditions	0 to 95 PCT	Standards	ANSI/UL 1449 Third Edition Type 4,1283, CUL recognized, CE, ROHS
Application	Critical industrial loads drawing up to 20 Amps of continuous current, microprocessor-based products, including industrial PLCs, OEM applications, and motion control systems.	UPC	633914074340
