HAMMOND MANUFACTURING EN4SD20166GY Eclipse Series Enclosure Mild Steel NEMA 4, IP66 508 mm H x 406 mm W x 152 mm D Gray

Manufacturer #:EN4SD20166GY


Wall mount enclosure type 4 constructed of 16 gauge mild steel with ANSI 61 smooth grey. Hinge door with quarter turn/handle. Smooth, continuously welded seams ground smooth. Doors may be easily removed for modifications and are interchangeable. Seamless poured-in place gasket. Hinges are constructed from 304 stainless steel. Designed to enclose electrical and/or electronic equipment and protect against harsh, industrial environments for wall mount applications.


Brand Name Hammond Manufacturing Sub Brand Eclipse Series
Item Name Enclosure Type Single Door, One Lock
Width 406 mm Depth 152 mm
Height 508 mm NEMA Rating NEMA 4, IP66
Series Eclipse Mounting Type Wall
Material Mild Steel Finish Powder Coated
Color Gray Standards UL 508A Type 3R, 4, and 12, CSA Type 3R, 4, and 12, Complies with NEMA Type 3R, 4, and 12, IEC 60529, IP66, CE, RoHS Compliant
Application Enclose Electrical and/or Electronic Equipment and Protect Against Harsh, Industrial Environments for Wall Mount Applications UPC 623980447087
